Name: CTDCG-14 Three Axle Six Roller Vehicle Chassis Dynamometer Automotive Dyno Horse Power Machine
Brand: Cartesy Diagnosis Technology CO.,Ltd
SKU: CTDCG-15
Price: 23.00 USD
Availability: InStock

Home > products > Automobile Chassis Dynamometer >

CTDCG-14 Three Axle Six Roller Vehicle Chassis Dynamometer Automotive Dyno Horse Power Machine

Three Axle Vehicle Chassis Dynamometer

Six Roller Vehicle Chassis Dynamometer

15000kg automotive dyno

Place of Origin:

China

Brand Name:

Cartesykj

Certification:

Model Number:

CTDCG-15

Request A Quote

CTDCG-14 Three Axle Six Roller Vehicle Chassis Dynamometer Automotive Dyno Horse Power Machine

Product Details

Name:

Automobile Chassis Dynamometer

Car Fitment:

BMW - Europe

Warranty:

12 Months

Port:

Guangzhou

Maximum Axle-load (kg):

15000

Maximum Absorption Power (kw):

350

Maximum Braking Torque (Nm):

3500

Maximum Testing Speed (km/h):

160

Working Voltage (current):

96V ×35A

The Power Supply:

220V ±10% 50HZ

Highlight:

Three Axle Vehicle Chassis Dynamometer

Six Roller Vehicle Chassis Dynamometer

15000kg automotive dyno

Payment & Shipping Terms

Minimum Order Quantity

1set

Price

$4,323.00 - $43,239.00/sets

Packaging Details

Wooden packing

Delivery Time

20~25 working days

Payment Terms

L/C, T/T

Supply Ability

1 Set/Sets per Month

CTCDG-15 AutoThree Axis Six Roller Vehicle Chassis Dynamometer Horsepower Dynamometer

Get Best Price

video

CTDTG-15 Auto Vehicle Chassis Dynamometer Horsepower Dynamometer Three Axis Six Roller

Get Best Price

video

New energy vehicle operation safety performance testing line Four-wheel drive automobile chassis dynamometer

Get Best Price

video

CTDCG-3-4WD Auto Car Vehicle Test Lane Vehicle Chassis Dynamometer horse power machine

Get Best Price

Contact Now

Product Description

Horse Power Machine CTDCG-14 Three-Axle Six-Roller Automobile chassis dynamometer

Product description:

Vehicle chassis dynamometer is mainly used for vehicle dynamics property, emissions and fuel consumption, (used in conjunction with fuel consumption meter, fuel consumption meter etc.) test, can complete car economy experiment, dynamic experiment and reliability experiment about special experiment and auto transmission system, chassis power output can be detected, torque, speed, distance, acceleration time, sliding distance and other data. So it divided in two kind of chassis dynamometer.

Features:

1. through high precision dynamic balancing, surface coating roller have high joint strength, abrasion resistance, adhesion coefficient is 0.92 or higher

2. Equipped with adjustable gear wheel, in order to guarantee the front drive vehicles test do not produce lateral slip; safe and reliable

3. With fuel consumption meter can be measured load condition of fuel consumption

4. The body is made of high quality flat MS Windows machine, ability is all ready, friendly interfaces, strong networking and it is convenient

5. Retrieve testing data, automatically print the results

Technical parameters

Model	CTDCG-3	CTDCG-10	CTDCG-15
Maximum axle-load (kg)	3000	10000	15000
Maximum absorption power (kw)	160	250	350
Maximum braking torque (Nm)	1600	2500	3500
Maximum testing speed (km/h)	130	130	160
Drum diameter x length (mm)	∮216×1000	∮318×1000	∮373×1000
center distance (mm)	480	495	600
Inside the drum width/width (mm)	700/2700	700/2700	700/2700
Working voltage (current)	96V ×35A	96V ×35A	96V ×35A
The power supply	220V ±10% 50HZ	220V ±10% 50HZ	220V ±10% 50HZ

CTDCG-14 Three Axle Six Roller Vehicle Chassis Dynamometer Automotive Dyno Horse Power Machine 0

Packing & Delivery

Wooden packing

FAQ

1. who are we?
We are based in Guangdong, China, start from 2011,sell to Domestic Market(50.00%),South Asia(10.00%),Africa(10.00%),Eastern Europe(10.00%),Oceania(5.00%),Western Europe(5.00%),Eastern Asia(5.00%),Northern Europe(3.00%),North America(2.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Vehicle Sideslip Tester,Roller brake tester with axle load,flat plate test line,Automobile power performance and Chassis dynamometer,Vehicle suspension performance Tester

4. why should you buy from us not from other suppliers?
Multi design of overall system scheme Site layout planning and Technological Consulting Systematic site installation and training Online daily maintenance and technical support

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,EXW；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,PayPal,Cash;
Language Spoken:English,Chinese
