Vehicle inspection equipment CTWC-K Vehicle Dimensions Scanning System inspection the vehicle dimension
Introduction:
Experiencing years of high developing transportation business, a new technology is required for inspection the vehicle dimension, in case of illegal modification, over-sized vehicle. etc. Therefore, based on state of laser technology and 3D-cloud data processing capacity, Cartesykj develops laser scanning system to measure the dimension data for all types of vehicle.
Main features:
FOH(Front Over Hang)and ROH(Real Over Hang)both can be detected by 4 Radars.
For automatically measurement of vehicle dimension, including length, height, width and axle distance, without manual intervention.
High pixel, high rate feedback, laser durable design.
High measurement accuracy: compared with similar products using video, grating and other technical principles, the measurement accuracy of lidar products is much higher than that of other products. The detection process is visualized.
Integrated electric design, free of maintenance, quick installation and commissioning.
The system has the function of fault self-test.
The installation mode is flexible; Wide working temperature design, all-weather work is not affected by weather and climate.
| Model | CTWC-K |
| Test Mode | Non contact dynamic |
| Resolution | 1mm |
| Length Test Range | 2-60m |
| Width Test Range | 1.5-6M |
| Height Test Range | 1.2-8m |
| Dimension(L × W × H) Accuracy | ≤±0.8% |
| Power Supply | AC220V ± 20% 50/60Hz ± 5% |
| Protocol | RS-232/485/422/RJ-45 |
| Laser Radar Scanning Unit | 3 pcs auto movement |
| Operating temperature | -55℃~+70℃ |
| Environmental humidity |
≤ 98% |
| Speed range | 0～ 1OO KM |
| Power Comsumption | ≤100W |
